IRF9Z24N MOSFET
Rs.100.00
Skip to product information
IRF9Z24N MOSFET
IRF9Z24N MOSFET
The IRF9Z24N MOSFET is a P-Channel power MOSFET for switching, power management, motor control, DC-DC converters, power supplies, reverse-polarity protection, and industrial electronics. Its TO-220 package supports convenient mounting and thermal management.
Technical Specifications
| Type | P-Channel MOSFET |
| Drain-Source Voltage (Vds) | -60V |
| Continuous Drain Current (Id) | -17A |
| RDS(on) (Max) | 0.1Ω |
| Gate-Source Voltage (Vgs) | ±20V |
| Power Dissipation | 94W |
| Package | TO-220 |
| Applications | Power Supplies, Load Switching, Battery Protection, Motor Drivers |
Rs.100.00
Pickup available at Robostan
Usually ready in 24 hours
IRF9Z24N MOSFET
The IRF9Z24N MOSFET is a P-Channel power MOSFET for switching, power management, motor control, DC-DC converters, power supplies, reverse-polarity protection, and industrial electronics. Its TO-220 package supports convenient mounting and thermal management.
Technical Specifications
| Type | P-Channel MOSFET |
| Drain-Source Voltage (Vds) | -60V |
| Continuous Drain Current (Id) | -17A |
| RDS(on) (Max) | 0.1Ω |
| Gate-Source Voltage (Vgs) | ±20V |
| Power Dissipation | 94W |
| Package | TO-220 |
| Applications | Power Supplies, Load Switching, Battery Protection, Motor Drivers |
