FR FNB48S BT USB Tester
FR FNB48S BT USB Tester
FR FNB48S BT USB Tester
The FR FNB48S BT USB Tester is a feature-rich USB voltage and current meter with built-in Bluetooth connectivity, making it perfect for engineers, developers, and DIY testers who want remote monitoring and real-time logging.
Compatible with both USB-A and USB-C ports, this tester provides accurate data for voltage, current, power, capacity, resistance, and more. Its PD and QC trigger functionality allows for precise control and testing of fast charging modes. The built-in Bluetooth allows connection to mobile apps for graphical logging and remote display.
Ideal use of FR FNB48S BT USB Tester is for power banks, fast chargers, PD adapters, mobile diagnostics, and embedded USB projects.
Key Features:
- Supports USB-A & USB-C ports
- Built-in Bluetooth for real-time data on mobile
- ⚡ PD/QC trigger support (PD2.0/PD3.0/QC2.0/QC3.0)
- Displays Voltage, Current, Power, Energy, Resistance, Capacity, and Time
- 1.44" TFT Color Screen
- Protection alerts for over-voltage/current
- App support for live data graphing
- USB-C bidirectional current flow
Technical Specifications:
| Specification | Details |
|---|---|
| Model | FR FNB48S BT |
| Display | 1.44" TFT Color Screen |
| Ports | USB-A, USB-C |
| Voltage Range | 4V – 30V |
| Current Range | 0A – 5.1A |
| Power Measurement | Up to 150W |
| Bluetooth | Yes – App connectivity for logging & display |
| Trigger Support | PD2.0, PD3.0, QC2.0, QC3.0 |
| Capacity/Energy | Yes (mAh, Ah, Wh) |
| Resistance Measurement | Yes |
| Data Logging | On-screen and via mobile app |
| Use Case | USB Charger Testing, PD Fast Charge Debugging |
