FR FNB48S BT USB Tester

FR FNB48S BT USB Tester

₨9,250

Technical Specifications:

Specification Details
Model FR FNB48S BT
Display 1.44″ TFT Color Screen
Ports USB-A, USB-C
Voltage Range 4V – 30V
Current Range 0A – 5.1A
Power Measurement Up to 150W
Bluetooth Yes – App connectivity for logging & display
Trigger Support PD2.0, PD3.0, QC2.0, QC3.0
Capacity/Energy Yes (mAh, Ah, Wh)
Resistance Measurement Yes
Data Logging On-screen and via mobile app
Use Case USB Charger Testing, PD Fast Charge Debugging
Compare
Categories: , Tag: Brand:

Description

FR FNB48S BT USB Tester

The FR FNB48S BT USB Tester is a feature-rich USB voltage and current meter with built-in Bluetooth connectivity, making it perfect for engineers, developers, and DIY testers who want remote monitoring and real-time logging.

Compatible with both USB-A and USB-C ports, this tester provides accurate data for voltage, current, power, capacity, resistance, and more. Its PD and QC trigger functionality allows for precise control and testing of fast charging modes. The built-in Bluetooth allows connection to mobile apps for graphical logging and remote display.

Ideal use of FR FNB48S BT USB Tester is for power banks, fast chargers, PD adapters, mobile diagnostics, and embedded USB projects.

Key Features:

  • Supports USB-A & USB-C ports

  • Built-in Bluetooth for real-time data on mobile

  • ⚡ PD/QC trigger support (PD2.0/PD3.0/QC2.0/QC3.0)

  • Displays Voltage, Current, Power, Energy, Resistance, Capacity, and Time

  • 1.44″ TFT Color Screen

  • Protection alerts for over-voltage/current

  • App support for live data graphing

  • USB-C bidirectional current flow
